Viewing Head

0° Gemel Binocular, 360° Rotatable, w/Eye-Point Height Adjustable to Different Operator Heights

30° Gemel Trinocular Tube (Spectroscopical Ratio R: T=50:50 or 80:20), 360° Rotatable, w/Eye-Point Height Adjustable

30° Gemel Trinocular Tube w/Gemel Digital Viewing Head (6.3M/12M/20M Digital Modules for Options, USB3.0 Output),

360° Rotatable, w/Eye-Point Height Adjustable

30° Inclined Built-in Gemel Digital Viewing Head (16M/20M Digital Cameras for Options, WIFI or RJ45 Network Port

Output. Support Remote Full-Resolution Photo, Hotspot/Client Model Switch and Multi-Viewer), 360° Rotatable,

w/Eye-Point Height Adjustable

Eyepiece

Wide Field Plan Eyepiece PL 10X/20mm, with Reticle, Diopter Adjustable

Wide Field Plan Eyepiece PL 10X/20mm, with Reticle or Grid Plate, Diopter Adjustable

Objective

Infinity Plan Achromatic Objective (2X, 4X, 10X, 20X, 40X, 60X, 100X)

Infinity Plan Achromatic Phase Contrast Objective (10X, 20X, 40X, 100X)

Infinity Semi-Apochromatic Fluorescence Objective (4X, 10X, 20X, 40X, 100X)

Nosepiece

Quintuple Nosepiece or Quintuple Nosepiece (Brightness Memory)

Stage

2-Layer Wide Mechanical Ceramic-Paint Stage, w/X-axis Drive Precision: 0.1mm. 2-Slide Clip w/Moving Range

78mmx51mm

Condenser

N.A 1.25 Koehler Illuminator Condenser (w/Socket for Phase Contrast and Dark Field Acc.) with Aperture Diaphragm

Single-Band LED

Fluorescent

Reflective

Illumination

B4 TB- LED Fluorescent Module for TB w/Intensity Adjust Knob, BF/FL Switch Knob, Central Wavelength: 455nm

B1 Band Pass Filter LED Fluorescent Module w/Intensity Adjust Knob, BF/FL Switch Knob, Central Wavelength: 470nm

B2 Long Pass Filter LED Fluorescent Module w/Intensity Adjust Knob, BF/FL Switch Knob, Central Wavelength: 470nm

G1 Band Pass Filter LED Fluorescent Module w/Intensity Adjust Knob, BF/FL Switch Knob, Central Wavelength: 560nm

UV4 Long Pass Filter LED Fluorescent Module w/Intensity Adjust Knob, BF/FL Switch Knob, Central Wavelength: 385nm

Illumination System

100V-240V External Transformer, 3W LED w/Continuous Intensity Control, Type-C Interface Allows Portable Battery as a Power Source. USB Port Supports Microscope to Charge a Phone or Tablet. With ECO Energy Saving Function, LCD Display, Objective brightness Memory and Color Temperature Adjustment Function within 3000K and 7000K. The Body Can Supply Power to Fluorescent Illuminator and Wi-Fi Camera Module

100V-240V External Transformer, 3W or 5W LED w/Continuous Intensity Control, Type-C Interface Allows Portable Battery as a Power Source. USB Port Supports Microscope to Charge a Phone or Tablet. With ECO Energy Saving Function, LCD Display, Objective brightness Memory and Color Temperature Adjustment Function within 3000K and 7000K. The Body Can Supply Power to Fluorescent Illuminator and Wi-Fi Camera Module

Camera Accessories

0.35X, 0.5X, 0.65X, 1X Camera Adapter, Focus Adjustable

Other Accessories

Frosted Glass Accessories, Dark-Field Accessories, Phase Contrast Accessories, Color Filter, Telescope (Φ30), High Precision Type/General Type Micrometer with 0.01mm Scale Value
